Hillary Machinery supplies vertical turning lathes (VTLs) and vertical turning centers for precision machining of large, heavy and difficult-to-handle workpieces. Our vertical turning solutions include Hyundai WIA and Fives Giddings & Lewis machines for heavy-duty turning, boring and complex production applications, including configurations with live tooling.
Vertical turning lathes, commonly called VTLs or vertical turning centers, are CNC turning machines with a vertically oriented spindle and workholding system.
The vertical configuration uses gravity to help support the workpiece and can provide significant advantages when machining large, heavy or difficult-to-handle components.
Hillary Machinery offers Hyundai WIA and Fives Giddings & Lewis vertical turning solutions for precision and heavy-duty production applications.
A vertical turning lathe positions the workpiece on a horizontal chuck or table that rotates around a vertical axis. Cutting tools approach the rotating workpiece from above or from the side, depending on machine design.
This arrangement can simplify loading and workholding for large-diameter components that would be more difficult to support horizontally.
Several terms are commonly used for machines in this class, including vertical turning lathe, VTL, vertical lathe, vertical turning center and VTC.
While specific machine designs and capabilities vary, these terms generally describe turning machines where the workpiece rotates around a vertical spindle axis.
Vertical turning provides important advantages when workpieces become large, heavy or difficult to support on a conventional horizontal lathe.
Hillary Machinery offers a broad range of Hyundai WIA vertical turning centers for production turning applications.
Hyundai WIA LV-series machines are available across multiple chuck sizes, turning diameters and machining capacities, allowing manufacturers to match the machine to the workpiece and production requirement.
Hyundai WIA's LV-series vertical turning centers cover a wide range of workpiece sizes and production requirements.
Hillary Machinery's vertical turning offerings include Hyundai WIA machines from compact vertical turning centers through substantially larger machines for heavy workpieces.
Available families include:
Live-tool vertical turning centers expand the machine beyond conventional turning by adding powered-tool capability for operations such as drilling, milling and tapping.
Combining turning and secondary machining operations in one setup can reduce workpiece handling, improve feature-to-feature relationships and eliminate transfers to separate machining centers for suitable parts.
Hyundai WIA offers live-tool configurations within its LV-series vertical turning center lineup.
VTLs are particularly well suited for components with large diameters relative to their overall length.
The vertical orientation allows heavy components to rest naturally on the chuck or table rather than requiring the workholding system to support the entire workpiece horizontally.
Hillary Machinery also offers Fives Giddings & Lewis vertical turning solutions for large-part and heavy-duty machining applications.
These machines extend Hillary Machinery's vertical turning capability into demanding applications involving substantial workpiece dimensions, weights and machining requirements.
A conventional horizontal CNC lathe supports the workpiece along a horizontal spindle axis and is extremely effective for shafts, bar-fed components and parts where length is a major dimensional characteristic.
A vertical turning lathe can provide advantages when the component is large in diameter, relatively heavy or difficult to support horizontally.
The best machine orientation depends on workpiece diameter, length, weight, geometry and required machining operations.
Both vertical and horizontal multi-axis turning centers can combine turning with additional machining operations.
Machine selection should begin with the workpiece. Large-diameter and heavy components may favor vertical workholding, while shaft-type and bar-fed components typically favor horizontal machine configurations.
Depending on machine configuration and tooling, vertical turning centers can perform operations including:
VTLs and vertical turning centers are used across industries that manufacture large-diameter and heavy precision components, including:
Selecting a VTL should begin with the workpiece and machining process. Hillary Machinery can help evaluate:
Vertical turning centers can be integrated with robotic loading, part handling and other automation when the workpiece and production process are suitable.
Automation can increase productive spindle hours while reducing repetitive manual loading and unloading.
Explore Automated Turning Centers
VTL stands for vertical turning lathe. It is a turning machine where the workpiece rotates around a vertical spindle axis rather than a conventional horizontal axis.
The terms are often used interchangeably. Vertical turning center is commonly used for modern CNC machines with automatic tool changing, turrets or additional machining capabilities, while VTL remains a widely used general term for the machine class.
Vertical lathes are particularly effective for large-diameter, heavy and relatively short components that can benefit from gravity-assisted workpiece support.
Yes. Vertical turning centers equipped with live tooling can perform additional operations such as milling, drilling and tapping, depending on machine configuration.
Vertical workholding can simplify loading and support of large, heavy workpieces because gravity helps seat the component on the chuck or table. Horizontal lathes can be preferable for longer shaft-type and bar-fed parts.
Start with maximum workpiece diameter, height and weight, then evaluate chuck size, turning capacity, spindle torque, tooling, required secondary operations, accuracy and production volume.
Hillary Machinery can help evaluate your workpiece diameter, height, weight, material, machining operations and production requirements to determine the appropriate vertical turning solution.
View Available Vertical Turning Lathes or contact Hillary Machinery to discuss your vertical turning application.
