MURATEC MD200 TWIN SPINDLE WITH LIVE TOOLS & GANTRY LOADER
Automated Turning Centers
FULL TURN-KEY SOLUTION - With the power of many machines in one, the MD200 delivers accuracy, efficiency and improved productivity, while reducing the cost of labor. With drilling and milling in a single setup, this solution provides forward-thinking technology for lean systems and flexible line planning and delivers the power of many machines from a single source.
| Chuck Size (in) | 10" |
| Turning Diameter (in) | 7.87" |
| Turning Length (in) | 3.15" |
| Spindle(s) | 2 |
| Max RPM | 3,500 RPM |
| Power | 22 kW |
| Control | CNC (Fanuc) |
MD200 Machine Specs & Technical Data
Maximum Chuck Size 10 in
Number of Turret Stations 10 x 2
Maximum Spindle Speed 3500 rpm
Spindle Drive Motor 22 kW/30 min
Total Machine Weight (Approx.) 16314 lb
Live Tool Drive Motor 4.0 kW
Live Tool Maximum Speed 3000 rpm
Gantry Loader Workpiece Handling Capacity Φ200 mm x 120 mm , up to 8.0kg/piece
Spindle Nose Size JIS A2-6
Spec. of Axes X-axis 20 m/min | Z-axis 16 m/min
